Maintenance
Inspection guide
The purpose of this inspection guide is to aid you in identifying the intervals, based on page count, at which
parts must be inspected (for visible physical damage), cleaned, or replaced.
If any unsafe conditions exist, find out how serious the hazard could be and if you can continue before you
correct the hazard.
As you service the machine, check for the following:
• Damaged, missing, or altered parts, especially in the area of the On/O switch and the power supply
• Damaged, missing, or altered covers, especially in the area of the top cover and the power supply cover
• Possible safety exposure from any non-Lexmark attachments
Use the following table to determine when specified parts should be inspected:
EVERY
SERVICE
CALL
EVERY 100K EVERY
200K
NOTES
MEDIA TRAY—ALL
Tray insert Inspect Inspect Inspect
Media side guides Inspect Inspect Inspect Check for correct positioning.
Media end guide Inspect Inspect Inspect Check for correct positioning.
Separation pad Inspect Clean Clean Damp cloth
Tray lift gear assembly Inspect Inspect
Separation roller Inspect Inspect Replace Verify page count before replacing.
MEDIA FEEDERS—ALL
Pick roller Inspect Inspect Replace Verify page count before replacing.
MPF feed rollers Inspect Inspect Replace Water or alcohol
Sensor Clean Clean Brush or blower brush
TRANSFER ROLL
Transfer roll Inspect Inspect Replace
FUSER UNIT
Fuser unit Inspect Inspect Replace
Sensor (fuser exit) Clean Clean Blower brush
REDRIVE ASSEMBLY
Redrive assembly Inspect Replace Water
4514-6xx
Maintenance
329
