Lexmark MS517dn User Manual

200 paper jams
200 paper jam messages
Notes:
• Some error messages are applicable only to printer models with a polygon LSU (laser scanning unit).
• If the sixth digit character assigned to the serial number of the printer is in the P–Z range, then the
printer is installed with a polygon LSU (example: 4514 2ZHH 007CR).
Error code Description Action
200.01 Input sensor covered during warm-up sequence. Go to
“Sensor (input) static jam service check”
on page 92.
200.02 Input sensor covered too quickly. Go to
“Sensor (input) early/late arriving service
check” on page 92.
200.03 Page did not reach input sensor or was late
reaching input sensor, but was successfully
picked from the source.
Go to
“Sensor (input) early/late arriving service
check” on page 92.
200.05 Input sensor covered too long. Source = [x]. Go to
“Sensor (input) early/late arriving service
check” on page 92.
200.08 Page arrive at input senor at unexpected time. Go to
“Sensor (input) early/late arriving service
check” on page 92.
200.09 Printhead did not receive proper motor feedback
to start laser servo.
Go to
“Sensor (input) image jam service check”
on page 94.
200.10 Printhead motor not locked when media reaches
the input sensor.
Go to
“Sensor (input) image jam service check”
on page 94.
200.11 Printhead motor fell out of lock after page reaches
the input sensor.
Go to
“Sensor (input) image jam service check”
on page 94.
Mirror motor got locked, and then lost it again
before the initial lock timeout.
Go to
“Laser scanning unit (LSU) service check”
on page 136.
200.12 Printhead was not ready for media. Go to
“Sensor (input) image jam service check”
on page 94.
200.13 Media at input sensor is not the next media to be
imaged.
Go to
“Sensor (input) image jam service check”
on page 94.
200.14 Media reached the input sensor before EP was
ready.
Go to
“Sensor (input) image jam service check”
on page 94.
200.15 Input sensor covered too long. Source = [x]. Go to
“Sensor (input) early/late arriving service
check” on page 92.
200.16 Fuser motor stalled. Go to
“Main drive motor control jam service
check” on page 95.
200.21 No response from paper port driver while waiting
for the source to deactivate the Input Source
Ready flag to indicate it has initiated picking.
Go to
“Sensor (input) early/late arriving service
check” on page 92.
200.23 Laser servo never started due to potential conflict
with the transfer servo.
Go to
“Sensor (input) image jam service check”
on page 94.
4514-6xx
Diagnostics and troubleshooting
90

Lexmark MS517dn Specifications

General

Cables included	AC
Cartridge(s) included	Yes
Included cartridge capacity (black)	3000 pages
Color	No
Print technology	Laser
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	42 ppm
Duplex print speed (black, normal quality, A4/US Letter)	18 ppm
Processor cores	2
Noise level (idle)	15 dB
Processor frequency	800 MHz
Maximum internal memory	1280 MB
Sound pressure level (printing)	55 dB
Sound pressure level (duplex printing)	54 dB
Envelopes sizes	7 3/4, 9, 10, DL
Paper tray media types	Card stock, Envelopes, Labels, Plain paper, Transparencies
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Universal, Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Total input capacity	350 sheets
Total output capacity	150 sheets
Maximum input capacity	2000 sheets
Maximum number of input trays	5
Multi-Purpose tray input capacity	100 sheets
USB connector	USB Type-B
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Wi-Fi	-
Cabling technology	10/100/1000Base-T(X)
Security algorithms	LEAP, MD5, MSCHAPv2, PEAP, SNMPv3, SSL/TLS, TTLS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols (IPv4)	TCP/IP IPv4, AppleTalk
Supported network protocols (IPv6)	TCP/IP IPv6, TCP, UDP
Package depth	472 mm
Package width	432 mm
Package height	380 mm
Package weight	16700 g
Power consumption (off)	0.5 W
Power consumption (ready)	7 W
Power consumption (printing)	600 W
Energy Star Typical Electricity Consumption (TEC)	2.1 kWh/week
Display	LCD
Certification	ENERGY STAR, Blue Angel RAL-UZ-171, ICES-003 Class B, BSMI Class B, VCCI Class B, US FDA, UL 60950-1, FCC Class B, cUL CAN/CSA-C22.2 60950-1, NOM, CB EN/IEC 60950-1, CB EN/IEC 60825-1, CE DoC (EN 62301 Class B, EN 62311, CE EN/IEC 60950-1, CE EN/IEC 60825-1, EN 61000-3, EN 55022 Class B, EuP, EN 55024, UL), EFTA (CE), KCC, CCC, CECP, CEL, C-tick DoC, UL-AR, KC mark, UL GS mark, EC 1275, MET-I, ISO 532B, ECMA-370, TED, GOST-R, SII, TER
Product color	Gray
Display diagonal	2.4 \
Printing colors	Black
Country of origin	China
Maximum duty cycle	120000 pages per month
Recommended duty cycle	1500 - 14000 pages per month
Page description languages	Microsoft XPS, PCL 5e, PCL 6, PDF 1.7, PPDS, PostScript 3
Sustainability certificates	Blue Angel, ENERGY STAR
Operating altitude	0 - 2896 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Authentication method	802.1x

Weight and Dimensions

Depth	382 mm
Width	399 mm
Height	263 mm
