Lexmark MS517dn User Manual

950–958 errors
950–958 error messages
Error code Description Action
950.xx NVRAM mismatch failure—mismatch between
controller board EEPROM and control panel mirror.
".xx" codes:
• 00-29— mismatch between system and mirror
• 30-60—mismatch between secure and system
Go to
“NVRAM mismatch failure service check”
on page 153.
952.xx A recoverable NVRAM Cyclic Redundancy Check
(CRC) error occurred—n is the oset at which the
error occurred.
Go to
“NVRAM cyclic redundancy service
check” on page 154.
953.xx NVRAM chip failure with mirror part
Replace the controller board.
Go to
“Controller board removals” on
page 247.
954.xx NVRAM chip failure with system part
Replace the controller board.
955.xx The Code ROM or NAND flash failed the Cyclic
Redundancy Check (CRC) or the NAND
experienced an uncorrectable multi-bit failure.
Replace the controller board.
956.xx RIP card failure—processor failure
Replace the controller board.
956.01 Processor temperature is over the limit.
Replace the controller board.
957.xx RIP card failure—ASIC failure
Replace the controller board.
958.xx Controller Board NAND Failure—printer has
performed more than 100 shift and reflash
operations as a result of ECC bit corrections.
Replace the controller board.
NVRAM mismatch failure service check
Warning—Potential Damage: When replacing any of the following components:
• Control panel assembly
• Controller board assembly
Replace only one component at a time. Replace the required component and perform a POR before
replacing a second component listed above. If this procedure is not followed, the printer will be rendered
inoperable. Never replace two or more of the components listed above without a POR after installing each
one or the printer will be rendered inoperable.
4514-6xx
Diagnostics and troubleshooting
153

Lexmark MS517dn Specifications

General

Cables included	AC
Cartridge(s) included	Yes
Included cartridge capacity (black)	3000 pages
Color	No
Print technology	Laser
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	42 ppm
Duplex print speed (black, normal quality, A4/US Letter)	18 ppm
Processor cores	2
Noise level (idle)	15 dB
Processor frequency	800 MHz
Maximum internal memory	1280 MB
Sound pressure level (printing)	55 dB
Sound pressure level (duplex printing)	54 dB
Envelopes sizes	7 3/4, 9, 10, DL
Paper tray media types	Card stock, Envelopes, Labels, Plain paper, Transparencies
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Universal, Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Total input capacity	350 sheets
Total output capacity	150 sheets
Maximum input capacity	2000 sheets
Maximum number of input trays	5
Multi-Purpose tray input capacity	100 sheets
USB connector	USB Type-B
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Wi-Fi	-
Cabling technology	10/100/1000Base-T(X)
Security algorithms	LEAP, MD5, MSCHAPv2, PEAP, SNMPv3, SSL/TLS, TTLS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols (IPv4)	TCP/IP IPv4, AppleTalk
Supported network protocols (IPv6)	TCP/IP IPv6, TCP, UDP
Package depth	472 mm
Package width	432 mm
Package height	380 mm
Package weight	16700 g
Power consumption (off)	0.5 W
Power consumption (ready)	7 W
Power consumption (printing)	600 W
Energy Star Typical Electricity Consumption (TEC)	2.1 kWh/week
Display	LCD
Certification	ENERGY STAR, Blue Angel RAL-UZ-171, ICES-003 Class B, BSMI Class B, VCCI Class B, US FDA, UL 60950-1, FCC Class B, cUL CAN/CSA-C22.2 60950-1, NOM, CB EN/IEC 60950-1, CB EN/IEC 60825-1, CE DoC (EN 62301 Class B, EN 62311, CE EN/IEC 60950-1, CE EN/IEC 60825-1, EN 61000-3, EN 55022 Class B, EuP, EN 55024, UL), EFTA (CE), KCC, CCC, CECP, CEL, C-tick DoC, UL-AR, KC mark, UL GS mark, EC 1275, MET-I, ISO 532B, ECMA-370, TED, GOST-R, SII, TER
Product color	Gray
Display diagonal	2.4 \
Printing colors	Black
Country of origin	China
Maximum duty cycle	120000 pages per month
Recommended duty cycle	1500 - 14000 pages per month
Page description languages	Microsoft XPS, PCL 5e, PCL 6, PDF 1.7, PPDS, PostScript 3
Sustainability certificates	Blue Angel, ENERGY STAR
Operating altitude	0 - 2896 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Authentication method	802.1x

Weight and Dimensions

Depth	382 mm
Width	399 mm
Height	263 mm
