Exit Diags
Select this to exit the Diagnostics menu. The printer performs a POR and restarts in normal mode.
In MS610de, this menu appears as a soft button at the bottom right corner of t he display. This is al ways acce s sible
to the user from the main Diagnostics menu.
Configuration menu
The Configuration menu group consists of menus, settings, and operations that are used to configure a printer
for operation.
Entering the
Configuration
menu
1 Turn o the printer.
2 Press and hold 2 and 6 while turning on the printer.
Release the buttons when the splash screen appears.
Maintenance Counter Value
When this is selected, the printer displays the current value for the maintenance kit counter. This counter tracks
printer usage. A print job containing a single page increments the counter by one, while a duplex print job
increments the counter by two. When the value has reached the rated life of the maintenance kit, it reminds
the user that scheduled maintenance is required. See
“Maintenance kits” on page 330. The counter must be
reset after the maintenance kit is installed.
To view the maintenance counter value:
1 From the Configuration menu, navigate to Maintenance Counter Value.
The value is displayed and cannot be changed.
2 Press Back or X to return to the Configuration menu.
Reset Maintenance Counter
After installing the maintenance kit, the maintenance counter must be reset.
To reset the maintenance counter:
1 From the Configuration menu, navigate to Reset Maintenance Counter.
2 Depending on the printer model, press OK or touch to reset the counter, or press X to exit without
resetting the counter.
Once initiated, the operation cannot be canceled.
4514-6xx
Service menus
190
