Lexmark MS517dn User Manual

Error code Description Action
200.24 Measured gap at input sensor too small to meet
video delivery requirements. (Not enough time
since prior image
finished
to start new image).
Go to
“Sensor (input) image jam service check”
on page 94.
200.25 Input sensor covered too long. Source = [x]. Go to
“Sensor (input) early/late arriving service
check” on page 92.
200.29 Printhead drive control out of range due to an
external event beyond what the control is
designed to handle.
Go to
“Sensor (input) image jam service check”
on page 94.
200.30 Invalid printhead NVRAM. Go to
“Sensor (input) image jam service check”
on page 94.
200.31 Paper, in the middle of a job, at input sensor before
interrupt occurred.
Go to
“Sensor (input) early/late arriving service
check” on page 92.
200.32 Detected cover switch bounce. Go to
“Sensor (input) early/late arriving service
check” on page 92.
Printhead lost HSYNCs due to a glitch with the
laser safety interlock, for example, bouncy cover
switch.
Go to
“Laser scanning unit (LSU) service check”
on page 136.
200.33 Input sensor covered too quickly. Go to
“Sensor (input) early/late arriving service
check” on page 92.
200.35 Input sensor covered too long. Source = [x]. Go to
“Sensor (input) early/late arriving service
check” on page 92.
200.38 Interpage servo gap smaller than expected for
galvo oset target evaluation.
Go to
“Sensor (input) early/late arriving service
check” on page 92.
200.42 Rogue sheet at ACM sensor while flushing the
paper path prior to declaring tray 1 source empty.
Go to
“Sensor (input) early/late arriving service
check” on page 92.
200.44 Page from tray 1 did not reach the input sensor (or
the manual feed sensor, if present) after multiple
pick attempts. Page did make it out of the tray at
least as far as the ACM sensor.
Go to
“Sensor (input) early/late arriving service
check” on page 92.
200.84 Image data did not start on time. Go to
“Sensor (input) image jam service check”
on page 94.
200.87 During warm up flush, sheet detected too long
over input sensor.
Go to
“Sensor (input) early/late arriving service
check” on page 92.
4514-6xx
Diagnostics and troubleshooting
91

Lexmark MS517dn Specifications

General

Cables included	AC
Cartridge(s) included	Yes
Included cartridge capacity (black)	3000 pages
Color	No
Print technology	Laser
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	42 ppm
Duplex print speed (black, normal quality, A4/US Letter)	18 ppm
Processor cores	2
Noise level (idle)	15 dB
Processor frequency	800 MHz
Maximum internal memory	1280 MB
Sound pressure level (printing)	55 dB
Sound pressure level (duplex printing)	54 dB
Envelopes sizes	7 3/4, 9, 10, DL
Paper tray media types	Card stock, Envelopes, Labels, Plain paper, Transparencies
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Universal, Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Total input capacity	350 sheets
Total output capacity	150 sheets
Maximum input capacity	2000 sheets
Maximum number of input trays	5
Multi-Purpose tray input capacity	100 sheets
USB connector	USB Type-B
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Wi-Fi	-
Cabling technology	10/100/1000Base-T(X)
Security algorithms	LEAP, MD5, MSCHAPv2, PEAP, SNMPv3, SSL/TLS, TTLS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols (IPv4)	TCP/IP IPv4, AppleTalk
Supported network protocols (IPv6)	TCP/IP IPv6, TCP, UDP
Package depth	472 mm
Package width	432 mm
Package height	380 mm
Package weight	16700 g
Power consumption (off)	0.5 W
Power consumption (ready)	7 W
Power consumption (printing)	600 W
Energy Star Typical Electricity Consumption (TEC)	2.1 kWh/week
Display	LCD
Certification	ENERGY STAR, Blue Angel RAL-UZ-171, ICES-003 Class B, BSMI Class B, VCCI Class B, US FDA, UL 60950-1, FCC Class B, cUL CAN/CSA-C22.2 60950-1, NOM, CB EN/IEC 60950-1, CB EN/IEC 60825-1, CE DoC (EN 62301 Class B, EN 62311, CE EN/IEC 60950-1, CE EN/IEC 60825-1, EN 61000-3, EN 55022 Class B, EuP, EN 55024, UL), EFTA (CE), KCC, CCC, CECP, CEL, C-tick DoC, UL-AR, KC mark, UL GS mark, EC 1275, MET-I, ISO 532B, ECMA-370, TED, GOST-R, SII, TER
Product color	Gray
Display diagonal	2.4 \
Printing colors	Black
Country of origin	China
Maximum duty cycle	120000 pages per month
Recommended duty cycle	1500 - 14000 pages per month
Page description languages	Microsoft XPS, PCL 5e, PCL 6, PDF 1.7, PPDS, PostScript 3
Sustainability certificates	Blue Angel, ENERGY STAR
Operating altitude	0 - 2896 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Authentication method	802.1x

Weight and Dimensions

Depth	382 mm
Width	399 mm
Height	263 mm
