Lexmark MS517dn User Manual

• Updated “Laser scanning unit (LSU) removal” on page 316 to add a note regarding the sequence of
tightening the screws when reinstalling the polygon LSU.
August 7, 2015
• Updated “Electronics 1” on page 339 to add video cable with part number 41X0913, which is applicable
only to models with galvo LSU. Also added a description for PN 41X0362.
July 28, 2015
• Updated the wiring diagrams.
June 8, 2015
• Updated the parts catalog graphic (Assembly 1: Covers) and table to remove the control panels and their
corresponding part numbers.
May 13, 2015
• Updated “200 paper jam messages” on page 90 to add error codes specific to polygon laser scanning
unit (LSU).
• Updated “111 error messages” on page 134 to add error messages specific to polygon LSU. Added notes
to identify the type of LSU (polygon or galvo) and controller board the printer supports.
• Updated “Laser scanning unit (LSU) service check” on page 136 to include other ways to resolve LSU-
related issues. Added notes to identify the type of LSU (polygon or galvo) and controller board the printer
supports.
• Updated “Laser scanning unit (LSU) removal” on page 316 to add information on how to identify the type
of LSU (polygon or galvo) and controller board the printer supports.
• Updated “Electronics 1” on page 339 to specify whether the LSU that the printer supports is a polygon or
galvo. Added in the table these two FRUs: Polygon LSU frame (PN 41X0363) and Polygon LSU cable
(41X0759).
April 23, 2015
• Updated the 97y error code table and created “Network port error service check” on page 157 for the
97y error codes.
• Updated the 98y error code table and created “Option communication error service check” on page 158
for the 98y error codes.
• Updated the 99y error code table and created “Option communication error service check” on page 158
for the 99y error codes.
March 19, 2015
• 40X8305 FRU was renamed to ‘250‑sheet tray insert’
• 40X8261 FRU was renamed to ‘ACM assembly (standard tray only)’
• 40X8262 FRU was renamed to ‘ACM assembly (option tray only)’
December 4, 2014
• Updated the LSU removal procedure.
November 12, 2014
• Parts catalog Covers assembly—Added part number 41X0239.
4514-6xx
Service conventions and change history
26

Lexmark MS517dn Specifications

General

Cables included	AC
Cartridge(s) included	Yes
Included cartridge capacity (black)	3000 pages
Color	No
Print technology	Laser
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	42 ppm
Duplex print speed (black, normal quality, A4/US Letter)	18 ppm
Processor cores	2
Noise level (idle)	15 dB
Processor frequency	800 MHz
Maximum internal memory	1280 MB
Sound pressure level (printing)	55 dB
Sound pressure level (duplex printing)	54 dB
Envelopes sizes	7 3/4, 9, 10, DL
Paper tray media types	Card stock, Envelopes, Labels, Plain paper, Transparencies
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Universal, Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Total input capacity	350 sheets
Total output capacity	150 sheets
Maximum input capacity	2000 sheets
Maximum number of input trays	5
Multi-Purpose tray input capacity	100 sheets
USB connector	USB Type-B
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Wi-Fi	-
Cabling technology	10/100/1000Base-T(X)
Security algorithms	LEAP, MD5, MSCHAPv2, PEAP, SNMPv3, SSL/TLS, TTLS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols (IPv4)	TCP/IP IPv4, AppleTalk
Supported network protocols (IPv6)	TCP/IP IPv6, TCP, UDP
Package depth	472 mm
Package width	432 mm
Package height	380 mm
Package weight	16700 g
Power consumption (off)	0.5 W
Power consumption (ready)	7 W
Power consumption (printing)	600 W
Energy Star Typical Electricity Consumption (TEC)	2.1 kWh/week
Display	LCD
Certification	ENERGY STAR, Blue Angel RAL-UZ-171, ICES-003 Class B, BSMI Class B, VCCI Class B, US FDA, UL 60950-1, FCC Class B, cUL CAN/CSA-C22.2 60950-1, NOM, CB EN/IEC 60950-1, CB EN/IEC 60825-1, CE DoC (EN 62301 Class B, EN 62311, CE EN/IEC 60950-1, CE EN/IEC 60825-1, EN 61000-3, EN 55022 Class B, EuP, EN 55024, UL), EFTA (CE), KCC, CCC, CECP, CEL, C-tick DoC, UL-AR, KC mark, UL GS mark, EC 1275, MET-I, ISO 532B, ECMA-370, TED, GOST-R, SII, TER
Product color	Gray
Display diagonal	2.4 \
Printing colors	Black
Country of origin	China
Maximum duty cycle	120000 pages per month
Recommended duty cycle	1500 - 14000 pages per month
Page description languages	Microsoft XPS, PCL 5e, PCL 6, PDF 1.7, PPDS, PostScript 3
Sustainability certificates	Blue Angel, ENERGY STAR
Operating altitude	0 - 2896 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Authentication method	802.1x

Weight and Dimensions

Depth	382 mm
Width	399 mm
Height	263 mm
