Removing the mailbox from the printer and stand

1 Locate the latch on the horizontal bar.

2 Pullforwardonthetabuntilit

clicks

into place.

CAUTION: The mailbox is heavy, and requires two people to lift it.

Latch

Tab

Horizontal bar
