Lexmark W820 - Chapter 33: Replacing the Transfer Roller; Removing the Old Transfer Roller

122
33
Replacing the transfer roller
The transfer roller is one of the items in the maintenance kit. Replace it when the printer displays the
80 Scheduled Maintenance message.
Removing the old transfer roller
1 Turn the printer off.
2 If the envelope feeder is attached to the printer, remove it. See Removing the optional
envelope feeder.
3 If the duplex unit is attached to the printer, open the duplex unit door (Door E).
a Push up on the latch to release the door.
b Gently lower the door to the open position.
4 Pull up on the handle to open the printer side door (Door A). Gently lower the door to the open
position.
