Lexmark W820 - Removing the Mailbox Stand

155
Removing the mailbox stand
Two people are required to remove the upper portion of the mailbox stand.
1 Locate the tab on each side of the stand.
2 Push in on the tabs and lift the upper portion of the stand straight up.
3 Set the upper portion of the stand aside.
4 Remove the thumbscrews on the right and left side stand pieces. Save the thumbscrews.
Right side stand
piece (back view
of printer)
