Lexmark W820 - Removing the Divertor Cover

To Next Page

To Previous Page

164

2 Have someone push the finisher away from the printer until it slides off the stand.

Removing the divertor cover

1 Pull the two tabs on the divertor cover straight out using a flat blade screwdriver or a flat key.

2 Rotate the divertor cover up and over toward the standard bin to release it.

Downloaded From ManualsPrinter.com Manuals
