LEYBOLD MAG Series User Manual

GA05141_0702 - 09/2004
110
Operating Instructions for MAG
digital
-series
Valid for pumps Valid for convertersOperating Instructions
MAG.DRIVE
digital
from software version
302.18
GA 05.141/6.02
English
(July 2003)
GA 05.141/6.01
German
(July 2003)
MAG W 830 C
MAG W 1300 C
MAG 1500 CT
MAG W 1500 C, CT
MAG W 2200 C
MAG W 2800 C, CT
MAG W 3200 CT
MAG W 2200 C
Part No. 400081V0020
MAG.DRIVE
digital
from software version
303.00
GA 05.152/2.02
English
(July 2003)
MAG W 830
MAG W 1300
MAG W 2200
MAG W 2800
with CF flange
MAG.DRIVE
digital
from software version
302.18
KA 05154_0302
Engl. (April 04)
Suppl. for GA
05.141/6.02
KA 05154_0301
German (April 04)
Suppl. for GA
05.141/6.01
MAG W 1300 C
with ISO-K flange
MAG.DRIVE
digital
from software version
302.18
KA 05157_0202
Engl. (July 04)
Suppl. for GA
05.141/6.02
KA 05157_0201
German (July 04)
Suppl. for GA
05.141/6.01
MAG.DRIVE
digital
from software version
3.03.05
GA 05141_0702
English
(Sept. 2004)
GA 05141_0701
German
(Sept. 2004)
MAG W 830 C
MAG W 1300 C
MAG 1500 CT
MAG W 1500 CT
MAG W 2200 C
MAG W 2800 C, CT
MAG W 3200 CT
MAG W 830
MAG W 1300
MAG W 2200
MAG W 2800
