LEYBOLD MAG Series User Manual

GA05141_0702 - 09/2004
15
Description
1.6 Technical data
MAG W 830 C W 1300 C W 1300 C
High-vacuum flange DN 160 ISO-F 200 ISO-F 250 ISO-F
250 ISO-K
Pumping speed (PNEUROP)
for N
2
l·s
-1
700 1100 1220
for Ar l·s
-1
650 1050 1180
for H
2
l·s
-1
300 920 1020
Compression for N
2
> 5·10
7
> 10
8
> 10
8
Ultimate pressure as to DIN 28 400 mbar < 10
-8
< 10
-8
< 10
-8
Max. forevacuum pressure with N
2
mbar 2 2 2
Rotor speed min
-1
24,000 36,000 36,000
Run-up time min < 4 < 6 < 6
Braking time with/without venting min 1 / < 4 1 / < 6 1 / < 6
Cooling water
Cooling connection, threads G 1/4“
with Swagelok for tube OD mm 6.4 (1/4“) 6.4 (1/4“) 6.4 (1/4“)
or with John Guest fitting for tube mm – 6 6
Cooling water temperature °C 10 – 30
°F 50 – 86
Weight approx. kg 32
Max. high-vacuum flange temperature
short-time °C85
°F 185
for continuous operation °C60
°F 140
Vibration level at high-vacuum flange
at max. speed µm < 0.01
Forevacuum flange DN 40 KF 40 KF 40 KF
or - 25 KF -
Recommended backing pump
Dry commpressing pump with
pumping speed m
3
/h 100
or rotary vane pump TRIVAC D 65 BCS
Admissible ambient temperature °C5 – 40
°F 40 – 104
Storage temperature °C -10 – +60
°F 14 – 140
Max. relative air humidity 95% (non-condensing)
Degree of protection (EN 60529) IP 20

LEYBOLD MAG Series Specifications

General

Applications	Laboratory, medical, and industrial applications
Drive	Magnetic drive
Sealing	Hermetically sealed
Flow Rate	Varies depending on the model, ranging from a few liters per minute (LPM) to several tens of LPM. Consult specific model datasheets for precise values.
Max Pressure	Varies by model (typically up to 10 bar)
Power Supply	Typically available in various AC voltages (e.g., 115V, 230V) and frequencies (50/60 Hz)
Power Consumption	Varies depending on the model, ranging from a few watts to several hundred watts. Consult specific model datasheets for precise values.
Operating Temperature	Typically 0°C to +60°C
Weight	Varies depending on the model, ranging from a few kilograms to several kilograms. Consult specific model datasheets for precise values.
Dimensions	Varies depending on the model. Consult specific model datasheets for precise dimensions.
Materials	Stainless steel
