LEYBOLD MAG Series User Manual

2.1 Unpacking - storing - transpor-
tation
Remove the equipment from the transportation box and keep the packa-
ging. Make sure that the product has not been damaged during transpor-
tation. If this unit is damaged contact your carrier and inform Leybold if
necessary. For storage of the product, use the packaging provided.
Lift the pump by the crane eyelets.
You can position the pump on the base plate for transport with a lift-truck.
Protect the pump against slipping and tipping over.
Be careful not to damage the sockets and coolant connections
during transportation.
Do not stand below the pump while connecting or removing the
MAG.
The MAG is shipped in a sealed PE bag with desiccant. Do not open the
sealed package until immediately before installing.
Do not remove the covers and blanking flanges until you are ready to make
the connections, to ensure that the MAG is installed under the cleanest
possible conditions.
2.2 Operating environment
When using the MAG inside a magnetic field, the magnetic induction at the
pump housing must not exceed 5 mT; (1 mT (milliTesla) = 10 G (Gauß))
Exceeding this limit can cause excessive rotor heating due to the eddy cur-
rents generated in this situation. It is therefore necessary to provide suita-
ble shielding in such cases.
The standard version of the MAG is resistant to radiation at levels up to 10
3
Gy. (1 Gy (Gray) = 100 rad)
The ambient temperature must not exceed 40 °C (104 °F).
The noise level when the pump is running is below 70 dB(A) (EN ISO 2151).
No acoustic insulation is required.
GA05141_0702 - 09/2004
44
Installation
Caution
Warning
Keep the packaging
Radiation
Magnetic field
