GA05141_0702 - 09/2004
83
Plug-in control
3.10.4 Menu Set Converter
Menu item Description Adjustable value / option Ac-
cess
min. max. stan- Unit
value value dard
Relay 6 Option Relay with change-over contact; 0 10 0 - r/w on
the operator can select one of
the functions described in Table A
“Option relays” on next page
See also Relay outputs
(section 2.8.3)
Relay 7 Option The settings of the relays 7 to 9 0 10 7 - r/w on
can be changed similar to relay 6.
Relay 8 Option After each power off the relays 7 0 10 8 - r/w on
to 9 are in the default state.
Relay 9 Option See also Relay outputs 0 10 10 - r/w on
(section 2.8.3)
Threshold Threshold bearing temp. 0 200 70 °C r/w on
for option relay
Threshold Threshold motor current 0 150 100 0.1 A r/w on
for option relay
Threshold Threshold frequency 0 600 300 Hz r/w on
for option relay
P/N Analog Out Signal choice Analog Out 0...10 V
Setting of the selected parameters 0 1023 125 - r/w on
for the analog output
Definition:
U
Ana_out
= Para
Current
/Para
Max Value
*Scale factor* 10 V
For more information about
parameter numbers see Table B
“Parameters for the analog output”
on next page
Scaling Ana Out Scale factor for the analog output 0.00 100.0 1.00 - r/w on
Analog Input 2 Analog input 0...10 V; no function r/w off
optionally frequency setpoint Function frequency setpoint
via analog input 2
(10 V = max. frequency setpoint)
Start Delay Waiting time between start
command and acceleration 0 3600 0 s r/w off
Display Display language English r/w on
German
Bus Address Bus adress for the converter by 0 31 0 - r/w on
operation via
serial interface RS 232/485
Func. X14.45 Function of the digital input 0 2 1 - r/w off
option 1 (idle (no function) /
Stand-by mode / Failure reset)
Func. X14.46 Function of the digital input 0 2 2 - r/w off
option 2 (idle (no function) /
Stand-by mode / Failure reset)
Op.Hours/Cycles In the case of "Warning”, a warning Warning (Default) - r/w off
will be displayed as soon as the Alarm
number of permissible operating
hours or cycles is exceeded; in the
case of "Alarm” the system is shut
down or a restart is prevented.
Mains Down
Powersupply OK
Start Command
Freq. Setpoint
Pump Stand Still
Enter
Threshold
70 °C
Enter
Threshold
10.0 A
Enter
Threshold
300 Hz
Enter
P/N Analog Out
3 Param
Enter
Scaling Ana Out
1.00
Enter
Start Delay
0 s
Enter
Enter
Relay 8 Option
Start Command
Enter
Relay 9 Option
Mains Down
Enter
Relay 7 Option
Pump Stand Still
Venting
TMS OK
No Purgegas
No Cooling Water
Frequency
Set Converter
Enter
Motor Current
Relay 6 Option
Bearing Temp.
Enter
Analog Input 2
No Function
German
Enter
Bus Adress
0
Enter
Display
English
Func. X14.45
Standby Mode
Enter
Func. X14.46
Failure Reset
Enter
Op.Hours/Cycles
Warning
Enter
To Next Page
