LEYBOLD MAG Series User Manual

GA05141_0702 - 09/2004
5
Safety information
Parts of the pump can become so hot during operation (> 70 °C,
> 158 °F) that they represent a burn hazard:
Provide protection against contact with the hot components.
The converter has dangerous voltage levels.
Failure to strictly follow the instructions in this Manual can result in
death, severe bodily injuries or significant material damage.
Unauthorizes opening of the frequency converter voids the war-
ranty.
Before opening the converter, always disconnect it from the mains
and the pump!
Before disconnecting any cables make sure that the converter is
switched off and the pump has come to a standstill.
When applying external voltage in excess of 42 V to terminals of
the device, observe local safety regulations!
Unauthorized device conversion and modifications are prohibited
for safety reasons.
Only suitably qualified personnel are permitted to work on the
pump or converter. Personnel must be completely knowledgeable
of all warning information and measures which are specified in this
Instruction manual for transporting, installing, and operating the
unit.
Qualified personnel
Qualified electrical personnel in this instruction manual means a person
who has received electrical engineering instruction or is an electrical expert
in accordance with EN 60204, Part 1, 3.30 respectivly 3.55.
The device contains electrostatically sensitive devices (ESD)!
Ensure that no items like bolts, nuts, washers, pieces of wire, for
example, enter into the inlet of the pump. Foreign objects which
enter into the pump will generally cause severe damage. Damage
caused by the intake of foreign objects is not covered by our war-
ranty. For this reason always leave the supplied inlet screen in
place.
The equipment must not be exposed to drip or spray water.
Caution
Warning
Warning
Warning
Caution
