LEYBOLD MAG Series User Manual

GA05141_0702 - 09/2004
65
Installation
Fig. 48 Function diagram outputs, Part 2
1
5
6
9
1 +5V Power supply for plug-in control
2 TXD
3 RXD
4 n.c.
5 GND
6 -5V Power supply for plug-in control
7 Reset out for plug-in control
8 select plug-in control input
9 Boot input
Fig. 49 Connector assignment, interface X7 (front side)
0
X14.23/24/25/26
X14.6/7/8/9
X14.39/40/41/42
X
X14.50
X14.32/33
X14.28/29
+15 V
8
Venting
Threshold
0
1
2
4
5
6
Rotor displacement
PVW13peak
PVW24peak
PZ12peak
Current li
m
iting
80 mA
1
2
3
4
5
6
7
9
Pump standstill
Start command
Power supply o.k.
Threshold
Threshold
Motor- or bearing-
temperature
Motor current
Act. frequency
Function
signal relay
Function
analog output
Analog output
Analog ground
Scale
No cooling water
No purge gas
TMS temp. o.k.
Relay 6/7/8/9 Option
10
11
Power failure
Stand-by
