6. Capacity Tables
Ceiling Concealed Duct (High Sensible)
_ 21
Indoor Units
Heating capacity
Notes:
TC: Total Capacity(kW)
1.
Capacity tables show the representative value of conditions which may occur.
2.
is shown as reference. When selecting the outdoor units, avoid the out-
door air temperature range shown by
.
3.
In accordance with operation limits of outdoor unit, applicable range of capac-
ity tables is different.
4. Refer to Capacity Correction Factorin the outdoor unit PDBfor the actual per-
formance data of each indoor unitand outdoor unit combination.
Capacity
Index
Outdoor air
temp.
DB(°C) WB(°C)
Indoor air temp. (DB, °C)
16 18 20 21 22 24
TC TC TC TC TC TC
kW kW kW kW kW kW
-24.8 -25 9.2 9.2 9.1 9.1 9.1 9.1
-21.8 -22 11.1 11.1 11.1 11.1 11.1 11.0
-19.8 -20 11.7 11.7 11.6 11.6 11.6 11.6
-18.8 -19 12.0 11.9 11.9 11.9 11.9 11.9
-16.7 -17 12.5 12.5 12.5 12.4 12.4 12.4
-14.7 -15 13.2 13.2 13.1 13.1 13.1 13.0
-12.6 -13 13.8 13.7 13.7 13.7 13.6 13.6
-10.5 -11 14.4 14.4 14.3 14.3 14.3 13.9
-9.5 -10 14.7 14.7 14.6 14.6 14.6 13.9
-8.5 -9.1 14.9 14.9 14.9 14.9 14.9 13.9
-7 -7.6 15.4 15.3 15.3 15.2 14.9 13.9
-5 -5.6 16.0 15.9 15.9 15.4 14.9 13.9
-3 -3.7 16.7 16.3 15.9 15.4 14.9 13.9
0 -0.7 17.0 16.5 15.9 15.4 14.9 13.9
3 2.2 17.5 16.9 15.9 15.4 14.9 13.9
5 4.1 17.7 16.9 15.9 15.4 14.9 13.9
7 6 17.9 16.9 15.9 15.4 14.9 13.9
9 7.9 17.9 16.9 15.9 15.4 14.9 13.9
11 9.8 17.9 16.9 15.9 15.4 14.9 13.9
13 11.8 17.9 16.9 15.9 15.4 14.9 13.9
15 13.7 17.9 16.9 15.9 15.4 14.9 13.9
14.1
