2 _ Fresh Air Intake Unit
Indoor Units
Notes:
1. Capacities are based on the following conditions:
Cooling • Outdoor temp. 33°C[91.4°F]DB/ 28°C[82.4°F]WB
• Interconnecting Piping Length 7.5m
• Level Difference of Zero
Heating • Outdoor temp. 0°C[32°F]DB/ -2.9°C[26.78°F]WB
• Interconnecting Piping Length 7.5m
• Level Difference of Zero
2. Capacities are net capacities
3. Due to our policy of innovation some specifications may be changed without prior notification
4. To be added for more available Models
5. Indoor Unit Connection
6. EEV : Electronic Expansion Valve
7. Noise Level is Standard Mode
(for actual High Mode(factory set) condition, Noise Level may exceed the standard level by 1.5dBA)
Conversion Formula
kcal/h= kW x 860
Btu/h = kW x 3412
cfm = m
3
/min x 35.3
l/s = CMM x 1000/60
Type
Model Unit
kW
Cooling Capacity kcal/h
Btu/h
kW
Heating Capacity kcal/h
Btu/h
Casing
Dimensions(WxHxD)
Body
mm
inch
Coil
Rows x Columns x FPI
Face Area m
2
Type
Motor Output x Number
W
Running Current A
Fan
Air Flow Rate(H/M/L) CMM
(High Mode-factory set)
cfm
External Static Pressure
mmAq(Pa)
Drive
Motor type
Temperature Control
Sound Absorbing Thermal Insulation Material
Air Filter
Safety Device
Liquid Side mm(inch)
Pipe Connections
Gas Side mm(inch)
Drain Pipe(Internal Dia.)
mm
Net Weight kg(lbs)
Noise Level
(Sound Press, 1.5m, H/M/L)
dB(A)
Power Supply Ø, V, Hz
Refrigerant Control
Power cable mm
2
Transmission cable mm
2
ARNU48GBRZ4 ARNU76GB8Z4 ARNU96GB8Z4
14.1 22.4 28
12,100 19,300 24,100
48,100 76,400 95,900
13.5 21.4 26.7
11,620 18,410 23,000
46,115 73,080 91,360
Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate
1,230 x 380 x 590 1,562 x 460 x 688 1,562 x 460 x 688
48-7/16 x 14-31/32 x 23-7/32 61-1/2 x 18-1/8 x 27-3/32 61-1/2 x 18-1/8 x 27-3/32
3 x 13 x 19 3 x 20 x 19 3 x 20 x 19
0.38 0.59 0.59
Sirocco Fan Sirocco Fan Sirocco Fan
195 x 1 375 x 1 375 x 1
0.78 1.36 2.15
18.8/14.7/14.7 23.7/13.2/13.2 35.7/23.7/23.7
664/519/519 837/446/446 1261/837/837
18 22 22
Direct Direct Direct
BLDC BLDC BLDC
Microprocessor, Microprocessor, Microprocessor,
Thermostat for cooling Thermostat for cooling Thermostat for cooling
and heating and heating and heating
Foamed polystrene Foamed polystrene Foamed polystrene
Long Life Filter Long Life Filter Long Life Filter
Fuse Fuse Fuse
Ø9.52(3/8) Ø9.52(3/8) Ø9.52(3/8)
Ø15.88(5/8) Ø19.05(3/4) Ø22.2(7/8)
25 25 25
45(99) 73(161) 73(161)
41/40/38 45/43/43 47/45/45
1, 220 - 240, 50 1, 220 - 240, 50 1, 220 - 240, 50
1, 220, 60 1, 220, 60 1, 220, 60
EEV EEV EEV
CV1.5 x 3C CV1.5 x 3C CV1.5 x 3C
VCTF-SB1.0 ~ 1.5 x 2C VCTF-SB 1.0 ~ 1.5 x 2C VCTF-SB 1.0 ~ 1.5 x 2C
Fresh Air Intake Unit
No Connection Condition Combination
Fresh Air Intake Units only are connected with
outdoor units
Mixture connection with general Indoor unit and
Fresh Intake Unit
1
1) The total capacity of Fresh Air Intake Unit should be 50~100% of outdoor unit.
2) The max quantity of Fresh Air Intake unit is 4 Units.
2
1) The total capacity of indoor units (standard Indoor Unit + Fresh Air Intake Unit) should be 50~100% of out-
door unit.
2) The total capacity of Fresh Air Intake Unit should be less than 30% of the total capacity of indoor units.
2. Specifications
