LG MULTI V ARNU12GTRA4

Indoor unit
6. Capacity Tables
Ceiling Concealed Duct_Built in (Low Static) _ 9
Indoor Units
Cooling capacity
Notes:
TC: Total Capacity(kW)
SHC: Sensible Heat Capacity(kW)
1. Capacity tables show the representative value of conditions which
may occur.
2. Refer to Capacity Correction Factorin the outdoor unit PDBfor the
actual performance data of each indoor unitand outdoor unit com-
bination.
6.2 Heating Capacity
Capacity
Index
Outdoor air
temp.
DB(°C) WB(°C)
Indoor air temp. (DB, °C)
16 18 20 21 22 24
TC TC TC TC TC TC
kW kW kW kW kW kW
-24.8 -25.0 1.4 1.4 1.4 1.4 1.4 1.4
-21.8 -22.0 1.7 1.7 1.7 1.7 1.7 1.7
-19.8 -20.0 1.8 1.8 1.8 1.8 1.8 1.8
-18.8 -19.0 1.9 1.9 1.9 1.9 1.9 1.9
-16.7 -17.0 2.0 2.0 2.0 2.0 2.0 2.0
-14.7 -15.0 2.1 2.1 2.1 2.1 2.1 2.0
-12.6 -13.0 2.2 2.2 2.2 2.2 2.1 2.1
-10.5 -11.0 2.3 2.3 2.2 2.2 2.2 2.2
-9.5 -10.0 2.3 2.3 2.3 2.3 2.3 2.2
-8.5 -9.1 2.3 2.3 2.3 2.3 2.3 2.2
-7.0 -7.6 2.4 2.4 2.4 2.4 2.3 2.2
-5.0 -5.6 2.5 2.5 2.5 2.4 2.3 2.2
-3.0 -3.7 2.6 2.6 2.5 2.4 2.3 2.2
0.0 -0.7 2.7 2.6 2.5 2.4 2.3 2.2
3.0 2.2 2.7 2.7 2.5 2.4 2.3 2.2
5.0 4.1 2.8 2.7 2.5 2.4 2.3 2.2
7.0 6.0 2.8 2.7 2.5 2.4 2.3 2.2
9.0 7.9 2.8 2.7 2.5 2.4 2.3 2.2
11.0 9.8 2.8 2.7 2.5 2.4 2.3 2.2
13.0 11.8 2.8 2.7 2.5 2.4 2.3 2.2
15.0 13.7 2.8 2.7 2.5 2.4 2.3 2.2
-24.8 -25.0 1.9 1.9 1.8 1.8 1.8 1.8
-21.8 -22.0 2.2 2.2 2.2 2.2 2.2 2.2
-19.8 -20.0 2.4 2.4 2.3 2.3 2.3 2.3
-18.8 -19.0 2.4 2.4 2.4 2.4 2.4 2.4
-16.7 -17.0 2.5 2.5 2.5 2.5 2.5 2.5
-14.7 -15.0 2.7 2.7 2.6 2.6 2.6 2.6
-12.6 -13.0 2.8 2.8 2.8 2.8 2.7 2.7
-10.5 -11.0 2.9 2.9 2.9 2.9 2.9 2.8
-9.5 -10.0 3.0 3.0 2.9 2.9 2.9 2.8
-8.5 -9.1 3.0 3.0 3.0 3.0 3.0 2.8
-7.0 -7.6 3.1 3.1 3.1 3.1 3.0 2.8
-5.0 -5.6 3.2 3.2 3.2 3.1 3.0 2.8
-3.0 -3.7 3.4 3.3 3.2 3.1 3.0 2.8
0.0 -0.7 3.4 3.3 3.2 3.1 3.0 2.8
3.0 2.2 3.5 3.4 3.2 3.1 3.0 2.8
5.0 4.1 3.6 3.4 3.2 3.1 3.0 2.8
7.0 6.0 3.6 3.4 3.2 3.1 3.0 2.8
9.0 7.9 3.6 3.4 3.2 3.1 3.0 2.8
11.0 9.8 3.6 3.4 3.2 3.1 3.0 2.8
13.0 11.8 3.6 3.4 3.2 3.1 3.0 2.8
15.0 13.7 3.6 3.4 3.2 3.1 3.0 2.8
-24.8 -25.0 2.3 2.3 2.3 2.3 2.3 2.3
-21.8 -22.0 2.8 2.8 2.8 2.8 2.8 2.8
-19.8 -20.0 2.9 2.9 2.9 2.9 2.9 2.9
-18.8 -19.0 3.0 3.0 3.0 3.0 3.0 3.0
-16.7 -17.0 3.1 3.1 3.1 3.1 3.1 3.1
-14.7 -15.0 3.3 3.3 3.3 3.3 3.3 3.3
-12.6 -13.0 3.5 3.4 3.4 3.4 3.4 3.4
-10.5 -11.0 3.6 3.6 3.6 3.6 3.6 3.5
-9.5 -10.0 3.7 3.7 3.7 3.7 3.7 3.5
-8.5 -9.1 3.8 3.8 3.7 3.7 3.7 3.5
-7.0 -7.6 3.9 3.9 3.9 3.8 3.7 3.5
-5.0 -5.6 4.0 4.0 4.0 3.9 3.7 3.5
-3.0 -3.7 4.2 4.1 4.0 3.9 3.7 3.5
0.0 -0.7 4.3 4.1 4.0 3.9 3.7 3.5
3.0 2.2 4.4 4.3 4.0 3.9 3.7 3.5
5.0 4.1 4.5 4.3 4.0 3.9 3.7 3.5
7.0 6.0 4.5 4.3 4.0 3.9 3.7 3.5
9.0 7.9 4.5 4.3 4.0 3.9 3.7 3.5
11.0 9.8 4.5 4.3 4.0 3.9 3.7 3.5
13.0 11.8 4.5 4.3 4.0 3.9 3.7 3.5
15.0 13.7 4.5 4.3 4.0 3.9 3.7 3.5
2.2
2.8
3.6
