Dip Switch & Group Control Setting _ 5
Dip Switch &
Group Control Setting
1. Cassette, Duct, Ceiling & Floor, Ceiling Suspended, Floor Standing, Console, Fresh Air Intake Unit
1.3 2 Remote Control
n Wired remote controller 2 + Indoor unit 1
1. It is possible to connect two wired remote controllers with one indoor unit.
2. You can connect any of the types of 2nd generation indoor units to two wired remote controllers.
3. It is possible to use wireless remote controller at the same time.
4. It is possible to connect with Dry Contact and Central controller at the same time.
5. In case that the indoor unit has an abnormal problem an error code will be displayed on the wired remote
controller.
With the exception of the indoor unit with the error, you can control each indoor unit individually.
6. There isnʼt limits of indoor unit function
h Maximum 2wired remote controllers can be connected with 1 indoor unit.
