LG MULTI V ARNU12GTRA4

18 _ Console
Indoor Units
10. Installation
4. Installing Indoor unit
4-1 Installation on the Floor.
1. Fix up using 6 screws for floor installation.
6 screw (M4*25L)
64
159
(700)
(Unit : mm)
26
647
180
140
(600)
574
170
170
210
30.5
30.5
140
160
1. The location of hole is different depending on which side of the pipe is taken out.
2. Drill a hole(Ø70mm) in the point indicated by symbol in the illustration as below
(Unit : mm)
45
90 75
Left bottom piping
Right bottom piping
Left/right piping
Right back piping
60
40
50
Wall
45
90
75
Left back piping
Right back piping
45
3. Refrigerant Piping
- The suggested shortest pipe length is 5m,in order to avoid noise from the outdoor unit and vibration.
NOTICE
