LG MULTI V ARNU12GTRA4

Indoor unit
12 _ Ceiling Cassette 4-way
Indoor Units
Model Gas Liquid
4. Piping Diagrams
Heat Exchanger
Turbo Fan
Th3
Th1
Th2
lndoor unit
EEV
:Heating
:Cooling
Filter
Filter
Refrigerant pipe connection port diameter
[Unit: mm(inch)]
ARNU05GTR*4
ARNU07GTR*4
ARNU09GTR*4
ARNU12GTR*4
ARNU15GTQ*4
ARNU18GTQ*4
ARNU21GTQ*4
ARNU24GTP*4
ARNU28GTP*4
ARNU30GTP*4
ARNU36GTN*4
ARNU42GTM*4
ARNU48GTM*4
ARNU54GTM*4
Ø12.7(1/2)
Ø12.7(1/2)
Ø12.7(1/2)
Ø12.7(1/2)
Ø12.7(1/2)
Ø12.7(1/2)
Ø15.88(5/8)
Ø15.88(5/8)
Ø15.88(5/8)
Ø15.88(5/8)
Ø15.88(5/8)
Ø15.88(5/8)
Ø15.88(5/8)
Ø15.88(5/8)
Ø6.35(1/4)
Ø6.35(1/4)
Ø6.35(1/4)
Ø6.35(1/4)
Ø6.35(1/4)
Ø6.35(1/4)
Ø9.52(3/8)
Ø9.52(3/8)
Ø9.52(3/8)
Ø9.52(3/8)
Ø9.52(3/8)
Ø9.52(3/8)
Ø9.52(3/8)
Ø9.52(3/8)
LOC. Description
Th1 Room thermistor
Th2 Pipe in thermistor
Th3 Pipe out thermistor
