7. External Static Pressure (E.S.P) & Air Flow
Indoor unit
24 _ Ceiling Concealed Duct (High Sensible)
Indoor Units
ARNU07GBGA4, ARNU09GBGA4, ARNU12GBGA4, ARNU15GBGA4
Capacity Mode Set value
Standard
ESP(mmAq(Pa))
CMM
Lower Limit of External
Static Pressure(mmAq(Pa))
Upper Limit of External
Static Pressure(mmAq(Pa))
7k
High
(factory set)
HI 98
6(59)
12.5(441)
6(59) 12(118)Mid 95 11.5(406)
Low 92 9.4(332)
Standard
HI 92
4(39)
14.6(516)
4(39) 8(78)Mid 89 13.7(484)
Low 86 12.3(434)
9k
High
(factory set)
HI 99
6(59)
12.8(452)
6(59) 12(118)Mid 95 11.5(406)
Low 92 9.4(332)
Standard
HI 93
4(39)
15.1(533)
4(39) 8(78)Mid 89 13.7(484)
Low 86 12.3(434)
12k
High
(factory set)
HI
100
6(59)
13.5(477)
6(59) 12(118)Mid 96 12.1(427)
Low 93 9.4(332)
Standard
HI
95
4(39)
16.6(586)
4(39) 8(78)Mid 92 15.1(533)
Low 89 13.7(483)
15k
High
(factory set)
HI
128
8(78)
13.8(487)
8(78) 18(177)Mid 106 11.8(417)
Low 103 8.3(293)
Standard
HI
100
6(59)
13.5(477)
6(59) 10(98)Mid 94 12.1(427)
Low 89 9.0(318)
Note:
1.The above table shows the available E.S.P. range.
2. The air flow of above model is increased by 20% depending on the Mode setting.
3. Above models are developed for high efficiency and high sensible heat.
If you want to use Zone control, you have to set ESP Value.
