Ceiling Concealed Duct(Low Static) _ 5
Indoor Units
3. Dimensions & Gravity point
Note
1. Unit should be installed in compliance with the installation manual
in the product box.
2. Unit shall be grounded in accordance with the local regulations or
applicable national codes.
774
ABCD
ARNU05GL1G4
ARNU07GL1G4
ARNU09GL1G4
ARNU12GL2G4
ARNU15GL2G4
ARNU18GL2G4
ARNU21GL3G4
ARNU24GL3G4
700 733 660
974 900 933 860
1,174 1,100 1,133 1,060
(unit: mm)
Name
1
Liquid pipe connection
2
Gas pipe connection
3
Drain pipe connection
4
Power supply connection
5
Air discharge
6
Air suction
Number Descripition
(unit : mm)
Unit size(5k,7k,9k,12k,18k) : 6.35
Unit size(21k, 24k) : 9.52
Unit size(5k,7k,9k,12k,18k) : 12.7
Unit size(21k, 24k) : 15.88
20
D
5
6
2
1
3
4
292
67 119
190
L1 : 366
L2 : 561
L3 : 755
100
94
700
190
20155
628
220
B
A
C
13534
Gravity point
L1 : 75
L2 : 78
L3 : 81
CHASSIS CODE: L1/L2/L3
Ceiling Concealed Duct (Low Static)
ARNU05GL1G4
ARNU07GL1G4
ARNU09GL1G4
ARNU12GL2G4
ARNU15GL2G4
ARNU18GL2G4
ARNU21GL3G4
ARNU24GL3G4
To Next Page
