LG MULTI V ARNU12GTRA4

18 _ Ceiling Concealed Duct(Low Static)
Indoor Units
ARNU05GL1G4, ARNU07GL1G4, ARNU09GL1G4
ARNU12GL2G4, ARNU15GL2G4, ARNU18GL2G4
Capacity Mode Set value
Standard
ESP(mmAq(Pa))
CMM
Lower Limit of
External Static
Pressure(mmAq(Pa))
Upper Limit of
External Static
Pressure(mmAq(Pa))
12k
High
(factory set)
HI
105
2.54 (25)
10.0
- 5(49)Mid
96 8.5
Low
89 7.0
Standard
HI 96
0 (0)
10.0
- 5(49)Mid 87 8.5
Low 78 7.0
15k
High
(factory set)
HI
119
2.54 (25)
12.5
- 5(49)Mid
105 10.0
Low
96 8.5
Standard
HI 109
0 (0)
12.5
- 5(49)Mid 96 10.0
Low 87 8.5
18k
High
(factory set)
HI
131
2.54 (25)
15.0
- 5(49)Mid
119 12.5
Low
105 10.0
Standard
HI 120
0 (0)
15.0
- 5(49)Mid 109 12.5
Low 96 10.0
Capacity Mode Set value
Standard
ESP(mmAq(Pa))
CMM
Lower Limit of
External Static
Pressure(mmAq(Pa))
Upper Limit of
External Static
Pressure(mmAq(Pa))
5k
High
(factory set)
HI 96
2.54 (25)
6.7
- 5(49)Mid
91 6.2
Low
86 5.5
Standard
HI 79
0 (0)
6.7
- 5(49)Mid 74 6.2
Low 69 5.5
7k
High
(factory set)
HI
100
2.54 (25)
7.5
- 5(49)Mid
93 6.5
Low
86 5.5
Standard
HI 86
0 (0)
7.5
- 5(49)Mid 78 6.5
Low 69 5.5
9k
High
(factory set)
HI
113
2.54 (25)
9.0
- 5(49)Mid
97 7.0
Low
86 5.5
Standard
HI 97
0 (0)
9.0
- 5(49)Mid 81 7.0
Low 69 5.5
Indoor unit
7. External Static Pressure (E.S.P) & Air Flow
