LG MULTI V ARNU12GTRA4

Indoor unit
Fresh Air Intake Unit _ 7
Indoor Units
6. Capacity tables and air flow
6.1 Capacity tables
ARNU48GBRZ4
Cooling
Heating
Note)
TC: Total Capacity (kW), SHC: Sensible Heat Capacity (kW)
WB: Wet Bulb, DB: Dry Bulb
1. The data shown in the table illustrates the supported operating ranges under the following conditions:
- Indoor and Outdoor Unit
- Effective piping length: 7.5 m
- Height differential: 0 m
2. The actual temperature may not match the temperature setting under some circumstances due to
the outdoor-air processing load or mechanical protection controls.
3. The system will not operate in fan mode when the outdoor air temperature is -5°C or below.
4.
Tropical region only.
Outdoor
air temperature
19℉WB 23℉WB 27℉WB 32℉WB 36℉WB 39℉WB 43℉WB 50℉WB 57℉WB
-7℃WB -5℃WB -2.9℃WB 0℃WB 2℃WB 4℃WB 6℃WB 10℃WB 14℃WB
℉DB ℃DB TC TC TC TC TC TC TC TC TC
Outdoor air
temperature
59℉WB 63℉WB 69℉WB 73℉WB 79℉WB 82℉WB 86℉WB 90℉WB 95℉WB 100℉WB
15℃WB 17℃WB 20℃WB 23℃WB 26℃WB 28℃WB 30℃WB 32℃WB 35℃WB 38℃WB
℉DB ℃DB TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
70 21 5.1 3.6 5.4 3.2 8.5 3.2 - - - - - - - - - - - - - -
73 23 5.1 4.3 5.2 3.9 8.2 3.7 - - - - - - - - - - - - - -
77 25 5.1 5.0 5.2 4.6 8.0 4.4 11.0 4.6 - - - - - - - - - - - -
81 27 5.0 5.0 5.1 5.1 7.3 5.1 10.9 4.8 14.0 4.5 - - - - - - - - - -
84 29 4.9 4.9 5.0 5.0 7.0 5.8 10.5 6.5 13.7 4.8 15.5 5.0 - - - - - - - -
88 31 4.9 4.9 5.0 5.0 6.7 6.5 9.5 6.0 13.3 5.5 15.1 5.3 16.3 4.6 - - - - - -
91 33 4.8 4.8 4.9 4.9 6.5 6.3 9.4 6.7 13.0 6.1 14.1 5.6 16.1 4.8 17.7 5.0 - - - -
96 35 4.8 4.8 4.9 4.9 6.4 6.4 9.2 7.4 12.7 6.8 14.0 6.2 15.9 5.5 17.5 5.2 - - - -
99 37 4.7 4.7 4.8 4.8 6.3 6.3 9.1 8.5 11.8 7.4 13.7 6.9 15.3 6.2 17.3 5.6 18.9 5.4 - -
104 40 4.7 4.7 4.8 4.8 6.2 6.2 9.0 8.8 11.4 8.5 13.4 7.0 15.0 7.2 17.1 6.7 18.7 5.7 21.7 4.6
109 43 - - 4.7 4.7 6.1 6.1 8.9 8.9 11.0 9.0 13.0 7.5 14.5 8.5 16.5 7.7 18.4 6.7 20.9 5.5
113 45 - - 4.1 4.1 5.7 5.7 8.4 8.4 10.2 9.5 12.2 8.2 13.9 9.2 16.0 8.2 17.1 7.1 19.5 6.0
118 48 - - - - 5.2 5.2 8.1 8.1 10.5 9.8 11.3 9.2 13.0 9.9 15.2 9.3 16.6 6.9 18.5 6.9
23 -5 14.7 - - - - - - - -
27 -3 14.2 14.4 - - - - - - -
32 0 - 14.0 14.2 - - - - - -
37 3 - - 13.6 13.8 14.0 - - - -
45 7 - - - 12.3 12.5 12.7 12.6 - -
52 11 - - - - 10.8 11.0 11.2 11.3 -
59 15 - - - - - 9.5 9.7 9.9 10.1
64 18 - - - - - - 8.7 8.9 9.0
68 20 - - - - - - 7.8 8.0 8.1
