Fresh Air Intake Unit _ 9
Indoor Units
6. Capacity tables and air flow
ARNU96GB8Z4
Cooling
Heating
Note)
TC: Total Capacity (kW), SHC: Sensible Heat Capacity (kW)
WB: Wet Bulb, DB: Dry Bulb
1. The data shown in the table illustrates the supported operating ranges under the following conditions:
- Indoor and Outdoor Unit
- Effective piping length: 7.5 m
- Height differential: 0 m
2. The actual temperature may not match the temperature setting under some circumstances due to
the outdoor-air processing load or mechanical protection controls.
3. The system will not operate in fan mode when the outdoor air temperature is -5°C or below.
4.
Tropical region only.
Outdoor
air temperature
19℉WB 23℉WB 27℉WB 32℉WB 36℉WB 39℉WB 43℉WB 50℉WB 57℉WB
-7℃WB -5℃WB -2.9℃WB 0℃WB 2℃WB 4℃WB 6℃WB 10℃WB 14℃WB
℉DB ℃DB TC TC TC TC TC TC TC TC TC
Outdoor air
temperature
59℉WB 63℉WB 69℉WB 73℉WB 79℉WB 82℉WB 86℉WB 90℉WB 95℉WB 100℉WB
15℃WB 17℃WB 20℃WB 23℃WB 26℃WB 28℃WB 30℃WB 32℃WB 35℃WB 38℃WB
℉DB ℃DB TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
70 21 10.2 6.9 13.2 6.9 17.1 7.2 - - - - - - - - - - - - - -
73 23 10.0 8.3 12.8 8.0 16.7 7.8 - - - - - - - - - - - - - -
77 25 9.8 9.0 12.1 9.0 16.1 9.2 22.3 9.0 - - - - - - - - - - - -
81 27 9.7 9.2 11.4 10.3 15.6 10.5 21.5 9.5 27.4 9.7 - - - - - - - - - -
84 29 9.5 9.3 11.2 10.6 15.2 11.8 20.9 10.8 26.9 10.1 30.2 9.3 - - - - - - - -
88 31 9.4 9.4 11.1 10.7 15.2 13.3 20.4 12.1 26.6 11.5 29.8 10.0 33.8 10.1 - - - - - -
91 33 9.4 9.4 11.0 10.8 14.8 13.7 20.0 13.5 26.1 12.8 28.0 10.6 33.2 10.6 38.0 11.2 - - - -
96 35 9.3 9.3 11.0 11.0 14.6 14.1 19.5 14.8 25.8 14.1 27.6 11.9 32.1 11.7 37.6 11.7 - - - -
99 37 9.3 9.3 10.9 10.9 14.5 14.3 19.0 15.7 25.4 15.4 26.6 13.1 31.8 13.0 37.0 12.2 44.2 12.9 - -
104 40 9.2 9.2 10.9 10.9 14.4 14.4 18.7 17.2 24.2 16.8 25.8 15.2 31.2 15.0 36.6 14.3 43.9 13.2 52.3 12.4
109 43 - - 10.8 10.8 14.3 14.3 18.5 18.0 23.8 17.4 25.0 16.4 29.7 16.0 34.4 15.6 42.4 14.7 50.5 13.1
113 45 - - 10.3 10.3 13.9 13.9 18.0 18.0 22.9 18.2 24.2 17.2 28.8 16.7 33.4 16.2 37.9 14.9 45.6 13.4
118 48 - - - - 13.4 13.4 17.2 17.2 22.0 19.0 23.4 18.0 27.9 17.8 32.7 17.2 32.3 15.6 38.0 13.7
23 -5 28.6 - - - - - - - -
27 -3 28.2 28.4 - - - - - - -
32 0 - 26.5 26.7 - - - - - -
37 3 - - 25.8 26.0 27.7 - - - -
45 7 - - - 25.1 25.3 25.0 24.4 - -
52 11 - - - - 21.7 21.9 22.1 22.5 -
59 15 - - - - - 19.4 19.6 19.8 19.6
64 18 - - - - - - 17.4 17.6 17.9
68 20 - - - - - - 16.0 16.2 16.4
