LG MULTI V ARNU12GTRA4

3. Dimensions
Indoor unit
6 _ Wall Mounted Unit (Standard)
Indoor Units
Display & signal receiver
Part Name
Front panel Air suction grille Installation plate Knockout hole
5
No.
2
4 3
1
Remark
289
50
210
45
895
341 323 128
37
790
205
675 327 422
264
70
CHASSIS CODE: SB
Wall Mounted
ARNU05GSB*4 ARNU07GSB*4 ARNU09GSB*4
ARNU12GSB*4 ARNU15GSB*4
Note
1. Unit should be installed in compliance with the installation manual in the product box. 2. Unit shall be grounded in accordance with the local regulations or applicable national codes.
