8 _ Wall Mounted Unit (Standard)
3. Dimensions
Indoor Units
CHASSIS CODE: SV
Wall Mounted
ARNU30GSVA4
ARNU36GSVA4
1. Unit should be installed in compliance with the installation manual
in the product box.
2. Unit shall be grounded in accordance with the local regulations or
applicable national codes.
3. The Unit is powered from the outdoor unit. Therefore power cable
should be connected with the outdoor unit.
Note
3
2
1
Left rear piping Right rear piping
43
43
140
150
167 Unit Outline 167
Installation plate
