6 _ ARTCOOL (Mirror)
Indoor Units
CHASSIS CODE: SC
ARTCOOL
ARNU18GSC*4
ARNU24GSC*4
Display & signal receiver
Part Name
Front panel
Air suction grille
Installation plate
Knockout hole
5
No.
2
4
3
1
Remark
Note
1. Unit should be installed in compliance with the installation manual
in the product box.
2. Unit shall be grounded in accordance with the local regulations or
applicable national codes.
3. The Unit is powered from the outdoor unit. Therefore power cable
should be connected with the outdoor unit.
[Unit : mm]
ÿ70
ÿ70
69
56
Right rear
piping
Left rear
piping
Installation Plate
Measuring Tape
Measuring Tape
Hanger
Place a level on raised tab
Unit Outline
207
105
460 570
To Next Page
