Console _ 13
Indoor Units
8. Electric Characteristicss
Symbols:
MCA : Minimum Circuit Amperes (A)
MFA : Maximum Fuse Amperes(see note 5)
kW : Fan Motor Rated Output(kW)
FLA : Full Load Amperes(A)
IFM : Indoor Fan Motor
Note :
1. Voltage Range
Units are suitable for use on electrical system where voltage supplied to unit terminals is not below or above the
listed range limits.
2. Maximum allowable voltage unbalance between phase is 2%.
3. MCA/MFA
MCA = 1.25 x FLA
MFA ≤ 4 x FLA
( Next lower standard fuse rating. Minimum 15A)
4. Select wire size based on the larger value on the MCA.
5. Instead of fuse, use Circuit Breaker.
Units
Model Type Hz Volts
Voltage Range
ARNU07GQAA4 QA 0.34 15 0.048 0.27 15 15
ARNU09GQAA4 QA 0.34 15 0.048 0.27 15 15
ARNU12GQAA4 QA 0.36 15 0.048 0.29 18 18
ARNU15GQAA4 QA 0.36 15 0.048 0.29 24 24
ARNU07GQAA4 QA 0.34 15 0.048 0.27 15 15
ARNU09GQAA4 QA 0.34 15 0.048 0.27 15 15
ARNU12GQAA4 QA 0.36 15 0.048 0.29 18 18
ARNU15GQAA4 QA 0.36 15 0.048 0.29 24 24
Power Supply IFM Input(W)
MCA MFA kW FLA Cooling Heating
Min.:198,
Max.:264
Min.:198,
Max.:242
50 220-240
60 220
To Next Page
