General Information _ 4
3. Nomenclature
ARN U G07 ATU 4
Serial Number
Chassis Name
Electrical Ratings
2:1Ø, 220V, 60Hz
6:1Ø, 220 - 240V, 50Hz
G:1Ø, 220 - 240V, 50Hz / 1Ø, 220V, 60Hz
Total Cooling Capacity in Btu/h
EX) 5,000 Btu/h Class ➝ '05' 18,000 Btu/h Class ➝ '18'
Combination of Inverter Type and
Cooling Only or Heat Pump
U: DC Inverter and H/P and C/O
System with Indoor Unit using R410A
ARN : Global line-up
CRN : Brazil line-up only
Combinations of functions
A:Basic function
L:Neo Plasma(Wall Mounted)
C:Plasma(Ceiling Cassette)
G: Low Static
U : Floor Standing without Case
ART COOL Type Panel Color
SB/SC - R:Mirror V:Silver W:White
Z : Fresh Air Intake Unit
General information
Indoor unit
To Next Page
