Liebert S600 - LED Indicator; Audible Alarm (Buzzer); LCD and Functional Keys

Vertiv|Liebert® S600 10kVA ~ 20kVA UPS | User Manual 38
1. The device has a gravity sensor function; thus, the LCD display direction will be changed according to the
device layout mode.
4.1.1 LED Indicator
The LED indicators are composed of run indicator and alarm indicator. Table 4-1 gives the indicator description.
Table 4-1 Definition of Indicators
Indica
tor
Colou
r
State
Description
Run
indicat
or
Green
On
UPS has Output
Blinki
ng
Inverter is Starting
Off
UPS has no output, Inverter is starting
Alarm
indicat
or
Yello
w
On
Alarm Occurs
Red
On
Fault Occurs
/
Off
No Alarm, No Fault
4.1.2 Audible Alarm (Buzzer)
UPS activity is accompanied by the two kinds of sound listed in Table 4-2.
Table 4-2 Description of audible alarm
Alarm sound
Meaning
One beep every 0.5 second
Sound is generated when the UPS critical alarm appears, such as
Inverter overload
One beep every second
Sound is generated when the UPS critical alarm appears, such as
battery low voltage
One beep every 3.3 second
Sound is generated when the UPS general alarm appears
Continuous beep
Sound is generated when the UPS fault appears, such as fuse or
hardware failure.
4.1.3 LCD and Functional Keys
The operator control and display panel provides five control keys, as described in Table 4-3.
Table 4-3 Description of Control Keys
Control key
Silkscreen
Description
Confirm
Used to confirm or enter
Up
Used to page up, turn left or add value, etc.
