Appendix 1 LCD Parameter Settings
Menu
Item
Setting Range
Default Setting
System
Auto restart
Disable, Enable
Enable
Auto restart delay
0～999 seconds
10; Single unit only
Guaranteed shutdown
Disable, Enable
Disable
Remote control
Disable, Enable
Enable
Remote power on delay
0～999 seconds
0
Remote shutdown delay
0～999 seconds
0
Redundant
NO, YES
YES
LBS select
Disable, Master, Slave
Disable; /20kVA only
IT system compatibility
Disable, Enable
Disable
Dry contact 1 (Output)
Low battery, On bypass,
On battery, UPS fault
Low battery
Dry contact 2 (Output)
Low battery, On bypass,
On battery, UPS fault
UPS Fault
Dry contact 3 (Input)
Battery mode shutdown,
Any mode shutdown,
Maintain mode
Maintain mode
Dry contact 4 (Input)
Battery mode shutdown,
Any mode shutdown,
Maintain mode
Maintain mode
Output
Voltage selection
220V, 230V, 240V
220V
Startup on bypass
Disable, Enable
Disable
Frequency Selection
Auto, BypEna; Auto,
BypDisa;
50Hz, BypDisa; 60Hz,
BypDisa
Auto, BypEna
Inverter sync range
±0.5Hz, ±1.0Hz, ±2.0Hz,
±3.0Hz, ±4.0Hz, ±5.0Hz
±3.0Hz
Bypass voltage upper
limit
+10%, +15%, +20%
+20%
Bypass voltage lower
limit
-10%, -20%, -30%, -40%
-40%
Bypass frequency range
±5Hz, ±10Hz
±10Hz
Run mode
Normal, ECO mode
Normal
Menu
Item
Setting Range
Default Setting
Output
ECO voltage range
±5%, ±10%, ±15%
±10%
ECO frequency range
±1Hz, ±2Hz, ±3Hz
±3Hz
ECO
requalification time 5, 15,
30 (min)
30
Output phase No.
1 phase, 3 phases
3 phases (/20kVA)
Parallel
Voltage selection
220V, 230V, 240V
220V
Frequency selection
Auto, BypEna; Auto,
BypDisa;
50Hz, BypDisa; 60Hz,
BypDisa
Auto, BypEna
Run mode
Normal, ECO mode
Normal
Redundant
NO, YES
YES
System parallel No.
1～4
1
Output phase No.
1 phase, 3 phases
3 phases (/20kVA)
Sync parallel parameters
Button
Button
Shared battery
Disable, Enable
Disable; /20kVA only
Local/Parallel battery
7～3000Ah
9Ah (5/6/10kVA)
