4.2.4 Laser Indirect Ophthalmoscope (LIO)
The controls on the LIO (refer to Fig. 4.8 a-b) are used to adjust the position of the
treatment laser beam to the Illumination spot. All other controls either adjust the
Illumination spot or the fitment of the unit for the doctor. More detailed breakdown
description can be found in the following pages.
Figure 4.8(a) Front View of LIO LDU Controls
Figure 4.8(b) Top View of LIO LDU Controls
5
2
1
3
4
6
10
8
9
7
