Lightmed LightLas 532 - Realignment Set Screw Location (X-Y Axis)

LightLas 532 – Operator's Manual Rev. No 01 Page 76 of 115
Note: Usually this step is unlikely to be realigned unless due to the outer force
impact during the transportation
Figure 5.26 Realignment set screw location (X-Y axis)
Figure 5.27 (a) Checking Field of View set-up
Figure 5.27 (b) Checking manipulator operation on the target
Y-axis Alignment
X-axis Alignment
