LightLas 532 – Operator's Manual Rev. No 01 Page 55 of 115
5.4 Setting Up the Laser System Parts
Preparation
All the possible items used during installation of the Green Laser are shown below in
Figure 5.3. From the top left-hand side in a clockwise direction the parts are:
1. Laser Console
2. Integrated Laser Delivery Unit Microscope assembly with Zoom unit
3. LIO Assembly
4. Fiber Delivery cable
5. Endoprobe Plug
6. Endoprobe
7. 4 Different Delivery Key Connectors
8. Attachment Laser Delivery Unit (New One without Micromanipulator-Truspot)
9. Microscope Laser Safety Filter units
10. Footswitch (including a Signal Receiver and a Footswitch Cable)
LIO
LIO
LIGHTMED
STOP
Delivery
Key
DANGER / CAUTION
Visible laser radiation when open
AVOID EYE OR SKIN EXPOSURE TO
DIRECT OR SCATTERED RADIATION
Only use with 532nm Laser
WARNING
1 2
10
3
4
5
6789
Figure 5.3
Laser System parts
