Maintenance 5
Hydraulics
Refill/topuphydraulicoil
¾ Add hydraulic oil to filling port.
Total fill quantity: approx. 27
.8 l
¾ Check oil level with dipstick (3) and top up
further until upper marking (4) is reached on
dipstick.
¾ Allow engine to idle for 3 minutes in upper
range (parking brake applied and accelera-
tor pedal depressed).
¾ Check oil level again (do no
tdrive).
Only then should the suction filter be changed.
¾ Close the bonnet.
NOTE
The hydraulic system will bleed itself when the
engine is running.
Hydraulic system: Check the oil
level.
ENVIRONMENT NOTE
Observe information regarding working with
consumables.
NOTE
Oil specifications: see Recommendations for
working materials
¾ Fully lower the f
ork carriage.
Operating Instructions – 394 807 10 01 EN – 07/2011 175
