Linde H45D - Type Sheet H 45 Elevated Drivers Compartment, as at 07;2011

Technical data 6
Type sheet H 45 elevated driver’s compartment, as at 07/2011
Type sheet H 45 elevated driver’s compartment, as at 07/2011
All data refers to standard equipment with standard 3800 mm lift mast.
Please observe the following:
1 Identification
1.1 Manufacturer Linde
1.2
Manufacturer’s type desig
nation
H45D
1.3 Drive Diesel
1.4
Operation
Seated
1.5
Load capacity/load
Q[kg]
4500
1.6
Load centre of gravity c [mm]
500
1.8 Load distance
x [mm]
525
1.9 Wheelbase
y [mm]
2038
2 Weight
2.1
Net weight kg
6505
2.2
Axle load with front/rear load
kg
9713/1292
2.3
Axle load without front/rear load
kg
2950/3555
3 wheels, chassis fr
ame
3.1
Front/rear tyres: polyurethane, rubber
SE (P)
3.2
Front tyre size
300-15
3.3
Rear tyre size
250-15
3.5
Number of wheels, front/rear (x = driven) 2x (4x)
31
/2
3.6 Front track width
b
10
[mm]
1190
32
3.7 Rear track width
b
11
[mm]
1122
4 Basic dimens
ions
4.1 Forward/backward fork tilt
α/β (°)
4.0/9.0
33
4.2
Lowered mast height
h
1
[mm]
2776
34
4.3 Free lift
h
2
[mm]
150
31
Bracketed value for twin tyres.
32
The track width may deviate from the indicated value, depending on the tyre variant.
33
L
ift height and equipment may change the backwards tilt.
34
With 150 mm free lift on standard lift mast.
Operating Instructions – 394 807 10 01 EN – 07/2011 223
