Linde H45D - Type Sheet H 40 Container, as at 07;2011

Technical data 6
Type sheet H 40 container, as at 07/2011
Type sheet H 40 container, as at 07/2011
All data refers to standard equipment with triplex 4075 mm lift mast.
Please observe the following:
1 Identification
1.1 Manufacturer Linde
1.2
Manufacturer’s type desig
nation
H40D
1.3 Drive Diesel
1.4
Operation
Seated
1.5
Load capacity/load
Q[kg]
4000
1.6
Load centre of gravity c [mm]
500
1.8 Load distance
x [mm]
483
1.9 Wheelbase
y [mm]
1998
2 Weight
2.1
Net weight kg
5936
2.2
Axle load with front/rear load
kg
8788/1148
2.3
Axle load without front/rear load
kg
2820/3116
3 wheels, chassis fr
ame
3.1
Front/rear tyres: polyurethane, rubber
SE (P)
3.2
Front tyre size
28x12.5–15
3.3
Rear tyre size
250–15
3.5
Number of wheels, front/rear (x = driven)
2x/2
3.6 Front track width
b
10
[mm]
1190
43
3.7 Rear track width
b
11
[mm]
1122
4 Basic dimens
ions
4.1 Forward/backward fork tilt
α/β (°)
5.0/7.5
44
4.2
Lowered mast height
h
1
[mm]
2161
4.3 Free lift
h
2
[mm]
1414
4.4 Lift
h
3
[mm]
4075
4.5
Raised mast height
h
4
[mm]
4822
43
T
he track width may deviate from the indicated value, depending on the tyre variant.
44
Lift height and equipment may change the backwards tilt.
Operating Instructions – 394 807 10 01 EN – 07/2011 229
