5 Maintenance
Load lift system
Load lift system
Working on the lift mast and at the
front of the truck
DANGER
When working on the lift mast, there is a risk of
becoming trapped and/or the lift mast accidentally
lowering.
If the lift mast or fork carriage is raised, no work
must be performed on the lift mast or at the front
of the forklift truck without observing the following
safety measures! These safety precautions are
sufficient only for general maintenance on the truck
(inspection and greasing). For repairs (e.g. chan-
ging chains, dismantling lift cylinders), additional
safety precautions must be taken. Contact your
authorised dealer.
Securing against tilting back
The lift mast must be secured against acciden-
tally tilting backwards
¾ Tilt the lift mast all the way back.
¾ Switch off the engine.
¾ Remove the ignition and stop key.
¾ Apply the parking brake.
Standard lift mast
FUNCTION: When lifting the inner mast,
the chain rollers are moved up with the
chains so that the fork carriage is lifted with
a transmission ratio of 2:1, due to the chain
deflection.
Securing the raised standard lift mast
DANGER
Check chain load!
Select the safety chain with sufficient load-bearing
capacity for the respective lift mast. Take the
maximum lift height into account.
¾ Extend the lift mast.
182 Operating Instructions – 394 807 10 01 EN – 07/2011
