Linde H45D - Page 233

Technical data 6
Type sheet H 40 elevated driver’s compartment, as at 07/2011
4 Basic dimensions
4.4
Lift
h
3
[mm]
3900
4.5
Raised mast height h
4
[mm]
4695
4.7
Overhead guard height (cab) h
6
[mm]
2783
4.8
Seat height, min./max. h
7
[mm]
1626
4.12
Coupling height h
10
[mm]
703
4.19
Total length l
1
[mm]
3984
4.20
Length including fork back l
2
[mm]
2984
4.21 Total width
b
1
/b
2
[mm]
1446/1423
29
4.22 Fork arm dimensions
s/e/l [mm]
50 x 120 x 1000
4.23
Fork carriage DIN 15173, class/form A, B
3A
4.24
Fork carriage width b
3
[mm]
1350
30
4.31
Ground clearance at mast
m
1
[mm]
158
4.32
Ground clearance at centre of wheelbase
m
2
[mm]
201
4.33
Aisle width for pallet 1000 x 1200 crosswise
A
st
[mm]
4355
4.34
Aisle width for pallet 800 x 1200 longitudinal A
st
[mm]
4555
4.35
Turning radius W
a
[mm]
2672
4.36
Smallest pivot point distance
b
13
[mm]
700
5Performanced
ata
5.1
Driving speed with/without load
km/h 21/21
5.2
Lifting speed with/without load
m/s 0.53/0.57
5.3
Lowering speed with/without load
m/s 0.52/0.57
5.5
Pulling force with/without load
N 28650/21959
5.7
Climbing capability with/without load
%
30.0/37.0
5.9 Acceleration with/without load
s
5.5/4.8
5.10
Service b
rake
Hydrostatic
7Drive/engine
7.1
Engine man
ufacturer/model
VW/CBJB
7.2
Engine pow
er rating as per ISO 1585
kW
55
29
T
he total width may deviate from the indicated value, depending on the tyre variant and fork carriage variant.
30
The fork carriage width may deviate from the indicated value, depending on the fork carriage variant.
Operating Instructions – 394 807 10 01 EN – 07/2011 221
