Overview 3
Display unit
Display element
Function
Possible malfunctions
Remedy
Text field (28)
Serves as display field for error
code display and charge status
display for the particle filter (in
line 1).
Charge status display:
- 0 symbols blacked out =>
particle filter empty
- 11 symbols blacked out =>
particle filter full
(29)"Lift mast positioning"
symbol
(special equipment)
- Lights up when the "Lift
mast positioning" function is
activated
Display (30)
Serves as a text display and
symbol display
(31) Air filter vacuum
indicator
(yellow)
- Lights up when the air filter is
excessively clogged.
Air filter clogged, change it.
(32) Coolant level indicator
(yellow)
- Lights up when the coolant
level is below the minimum
When the "Engine protection"*
function is activated):
- Truck moves at creep speed
(approx. 2 km/h)
Display in the text field (28):
- Error code
X203
Top up the coolant.
(33) Glow plug indicator
(yellow)
Function only available on
diesel trucks:
- Lights up whilst the glow plugs
are preheating, then goes out
- Flashes when a malfunction
exists in the engine or in the
engine control unit.
Identify the error using the
diagnostic program.
(34) Gas system error light
(red)
Function only available on LPG
trucks:
- Lights up if an error is detected
in the gas system.
Identify the error using the
diagnostic program.
(35) Engine malfunction
warning light
(yellow)
- Lights up if an error is detected
by the engine control unit.
Identify the error using the
diagnostic program.
*) The "Engine protection" function (special equipment) can be disabled using the diagnostic
program. Contact your authorised dealer.
Operating Instructions – 394 807 10 01 EN – 07/2011 27
