Operation 4
Standard equipment
certain circumstances, can cause the load to
slip from the fork arms.
In unfavourable situations, the engine can also
stall; as a result the "Do not start the engine"
symbol (3) appears in the display unit. A block
against repeat starting is active and the engine
cannot be started. Always leave the ignition
switched on until the "Do not start the engine"
symbol (3) goes out. In this time, the variable
displacement pump of the drive unit swivels
to the neutral position. Afterwards, the engine
can be started again.
NOTE
It is recommended that drivers familiarise
themselves with the function and effect of this
brake when there is no load on the truck. For
this purpose they should choose a route with
no other traffic, travelling at a low speed.
Parking brake
The multi-disc brakes are used as the parking
brake of the fork-lift truck.
Operating the parking brake
¾ Turn the parking brak
e lever (2) in a clock-
wise direction to the
stop.
The interlock (1) engages and the symbol in
the display unit lights up.
Releasing the parking brake
NOTE
The multi-disc brake will release only if the
engine is running.
¾ Turn the parking brake lever (2) gently in a
clockwise direction to release the interlock.
Operating Instructions – 394 807 10 01 EN – 07/2011 57
