CHAPTER 3A ENGINE 260/ 300 / 400 cc ATV SERVICE MANUAL09.0
CHAPTER 3 ENGINE PAGE. 3A- 69
INSTALLATION
1. Install:
zThermostatic valve
zThermostatic cover
3.12CARBURETOR （ATV260/300）
WARNING
Gasoline is extremely flammable and explosive under certain conditions.
Always stop the engine and refuel outdoors or in a well ventilated area.
Do not smoke or allow open flames or sparks in or near the area where refueling is performed
or where gasoline is stored.
If you get gasoline in your eyes or if you swallow gasoline, see your doctor immediately.
If you spill gasoline on your skin or clothing, immediately wash it off with soap and water and
change clothing.
Never start the engine or let it run in an enclosed area. Gasoline powered engine exhaust
fumes are poisonous and can cause loss of consciousness and death in a short time.
Never drain the float bowl when the engine is hot. Severe burns may result.
CARBURETOR REMOVEL
1. Remove:
zAuto choke lead coupler
2. Remove:
zFuel hose
