CHAPTER 3C ENGINE 100/125/150/200 SERVICE MANUAL09.0
CHAPTER 3C ENGINE PAGE.3C - 5 -
3.3.6 Transmission oil inspection (for
B-type 150/200)
1. Remove the oil level plug.
2. Wipe the oil on the plug and insert it into the filler
hole without screwing. The oil level should reach
the fourth mark.
3. When replacing the oil, remove transmission
case drain plug located on the front cover and
drain the oil..
4. Check the O-ring for damage and replace it if
necessary.
5. Install the drain plug.
6. Add SAE80W/90GL5 oil in the recommended
amount. Install oil dipstick.
7. The oil capacity of a new engine: 500ml. The top
filling for replacement: 450ml.
3.3.7 Crankcase oil inspection
8. Stand the engine on a level surface.
9. Have the engine run at idle speed for several
minutes. Inspect the oil level after the engine is
turned off 2-3 minutes.
10. Remove the oil level plug.
11. Wipe the oil on the plug and insert it into the filler
hole without screwing. The oil level should reach
the mark.
12. When replacing the oil, perform the first two
steps and remove the oil strainer to drain the oil.
13. Check the O-ring for damage and replace it if
necessary.
14. Add SAE15W/40SG oil in the recommended
amount.
15. The oil capacity of a new engine: 900ml. The
replacement volume: 750ml
.
16. Install the oil strainer, spring and strainer lid.
17. After replacement, start the engine and keep it
idling for 2-3 minutes and inspect the oil level
according to the above instructions.
