CHAPTER 8 ELECTRICAL ATV SERVICE MANUAL 09.0
CHAPTER 8 ELECTRICAL CTRICAL PAGE 8-
21
1. fuse
CHECK SWITCHES
NO CONTINUITY
Replace the fuse
2. Battery
Check the battery condition.
Refer to "BATTERY INSPECTION" section
INCORRECT
Clean battery terminals
Recharge or replace the battery
3 Main switch
CHECK SWITCHES
NO CONTINUITY
Replace the main switch
4. Fan motor(inspection 1)
Connect the battery to the fan motor.
Battery (+) lead→Green/Blue terminal
c
Battery (-) lead→Green ground d
Check the fan motor operation
DOES NOT MOVE
Replace fan motor
5. Fan motor (inspection 2)
Turn the main switch to off.
zRemove the thermo switch lead from
thermo switch.
zConnect jumper lead to thermo switch
leads.
zTurn the main switch to on
DOES NOT MOVE
The wiring circuit from battery to
fan motor is faulty. Repair
To Next Page
