CHAPTER 2 MAINTENANCE ATV SERVICE MANUA 09.0
CHAPTER 2 MAINTENANCE PAGE. 2-
21
EARLY DESIGN* Bolt M10 Attaching A-Arm and
Frame
30
41
LT* Only ATV 260 early
model
MANTENANCE-FREE PIVOT DESIGN Bolt M12
Attaching A-Arm and Frame
37-44
50-60 LT*
Nut M10X1.25 Attaching A-Arm to Ball Joint Stud 22-25 30-35
Screw M6 Attaching Ball Joint Mounting Bracket to
Front Absorber Strut body (MacPherson)
8
11 LT*
Swing Arm Pivot Left 14 19
Swing Arm Pivot Right 120 165
Threaded Pivot Nut (for swing arm)
120
165
Refer to SWING ARM
ASSEMBLY
INSTALLATION ，4.2
SWING ARM，CHAPTER
4A CHASSIS
Nut M14X1.5 Attaching Front Absorber to Frame
(MacPherson)
15-18
21-25 LT*
Nut M8 Binding Front Absorber and Front Absorber
Strut body (MacPherson)
15
21 LT*
Bolt M8 Attaching Front Caliper to Front Absorber
Strut body
18
25 LT*
Bolt M8 Attaching Upper Steering Clamp to Frame 12 16
Nut M8 Attaching Lower Steering Bearing Retainer to
Frame
12
16
Nut M10X1.25 Attaching Front Wheel to Front Wheel
Hub
20
27
Front （Drive） Axle Nut
Refer to FRONT HUB INSTALLATION
Screw M8 Attaching Front Brake Disc to Front Wheel
Hub
18
25 LT*
Nut M10X1.25 Attaching Rear Brake Disc to Rear
Brake
22-25
30-35 LT*
Rear Axle Nut M20X2 (for swing arm) 80 110.6
Rear Hub Retaining Nut M20X1 (for IRS) 101 137
Nut M10X1.25 Attaching Rear Caliper to Axle Tube 18 25 LT*
Bolt M12x30 Attaching Axle Tube and Swing arm to
Rear Gear-box
60
80
Bolt M12x35 Attaching Axle Tube to Swing arm 60-66 80-90
LT*---Apply Loctite™ 242
