CHAPTER 3A
ENGINE
260/
300
/
400
cc
A
TV
SERVICE
MANUAL09.0
CHAPTER
3
ENGINE P
AGE.
3A-
34
4. Instal:
z
V
alve cotters
c
NOTE:
Install the valve cotters while com pressing the
valve spring with a valve spring compressor and
attachment
d
.
5. Secure the valve cotters onto the valve stem
by tapping lightly with a piece of wood.
CAUTION:
Do not hit so much as to damage the valve.
