Operating manual and inspection booklet
Malfunctions
3435216 201
Fig. 200: Rear lamp assembly (rear)
9. Remove the bulb socket (2). Turn the bayonet mechanism
to the zero position and pull off the socket.
10. Replace the bulb.
11. Insert the bulb socket (2) in the rear lamp assembly.
Position the bayonet mechanism in the zero position, push
and as far as it will go.
Fig. 201: Reattaching the rear lamp
assembly
12. Carefully insert the rear lamp assembly.
13. Use a screwdriver to tighten the two screws (1) of the rear
lamp assembly.
